Burkert 8691 - 0 X2 C0 C Teach Function

63
Start-up
Sub-
index
Name Description
Access type
Factory
reset
0xB ValveMode
Valve mode
0 = Initialization
1 = AUTOMATC operating state
2 = Teach function active
3 = SafePos active
RO
0xC Device lock
Activate or deactivate local operation:
Button for manual operation inside the device is deacti-
vated to prevent unintentional operation
0 = Not deactivated (button is enabled)
1 = Deactivated (button is disabled)
RW x
0xE T_opening
Closing time:
Time, measured from the time when the lower tolerance
band is left until the time when the upper tolerance band is
reached,speciedinms
RO
0xF T_closing
Opening time:
Time, measured from the time when the upper tolerance
band is left until the time when the lower tolerance band is
reached,speciedinms
RO
Table 33: 0x2C0B Control head settings
10.4.3.23 0x2C0C Teach function
Sub-
index
Name Description
Access type
Factory
reset
0x1 Upper end position
Upper end position in mm
RO
0x2 Lower end position
Lower end position in mm
RO
0x3 T_open
Opening time:
Time, measured from the time when the upper tolerance
band is left until the time when the lower tolerance band is
reached,speciedinms
RO
0x4 T_close
Closing time:
Time, measured from the time when the lower tolerance
band is left until the time when the upper tolerance band is
reached,speciedinms
RO
0x5 Stroke mm
Valve stroke in mm:
Valve stroke measured during last teach function
RO
english
Type 8691, Rev. 2
