10.3.5.11 0x2C0F IO-Link SIO mode settings
Sub-
index
Name Description
Access type Data type Data memory
Factory
reset
0x1 SIO mode Select SIO mode:
0: Pin 4 (output)
Low = Valve not closed;
High =Valve closed
Pin 2 (output)
Low = Valve not open;
High =Valve open
1: Pin 4 (output)
Low = Valve not closed;
High =Valve closed
Pin 2 (input) as CMD set-point value
Low = Closed;
High =Open
PD set-point value is ignored
2: Pin 4 (output)
Low = Valve not open;
High =Valve open
Pin 2 (input) as CMD set-point value
Low = Closed;
High =Open
PD set-point value is ignored
Device must be restarted!
RW UINT8 x x
0x2 Output type Select switching mode of SIO outputs:
0: PNP (plus switching)
1: NPN (ground switching)
2: PP (push-pull output)
Device must be restarted!
RW UINT8 x x
Table 19: 0x2C0F IO-Link SIO mode settings
