Start-up
Sub-
index
Name Description
Access type Data type Data memory
Factory
reset
0x10 Pilot valve cycles
Number of pilot valve switching cycles
RO UINT32
0x11 Active warnings
Activewarnings(biteld)
Bit0: Travel accumulator threshold
reached
Bit1: Valve switching cycle threshold
reached
Bit2: Operating time threshold reached
Bit3: Opening time timeout
Bit4: Closing time timeout
Bit5: Calibration required
Bit6: Tolerance bands overlap
RO UINT16
0x12 Switching time out
counter
Number of switching time timeouts
RO UINT32
0x13 Active errors
Activeerrors(biteld)
Bit0: Switching time timeout
Bit1: Teach function error
Bit2: Position sensor error
Bit3: IO-Link set-point value error
Bit4: büS/CanOpen set-point value error
RO UINT16
0x15 Time diagnostic type
Select type of switching times for
diagnostics:
0: Use switching time based on CMD
set-point value (0x2C0B sub-index 0x4
and 0x5)
1: Use switching time based on position
(0x2C0B sub-index 0xE and 0xF)
RW UINT8 x x
0x17 Switching timeout
detection
Activate or deactivate switching time
timeout detection:
If activated, switching time timeouts are
detected whenever the end position is
not reached within a certain time (sub-
index 0x18)
0: Deactivated
1: Activated
RW UINT8 x x
0x18 Switching timeout
Select maximum time by which the end
position should be reached
RW UINT16 x x
Table 18: 0x2C0E Diagnostics
