Burkert 8691 - 0 X2100 Get Mapping Function; 0 X2101 Locating Function; 0 X2102 Blockdownload Config Function

57
Start-up
Bit7 Bit6 Bit5 Bit4 Bit3 Bit2 Bit1 Bit0
Gateway:
0 - Run
1 - Stop
0 if no gateway is sup-
ported by device
F(x):
0 - Run
1 - Stop
0 if no F(x) functionality
is supported by device
NAMUR mode:
0 - Automatic
1 - Manual
2 - Flash
NAMUR state
0 - Normal
1 - Diagnostics active
2 - Maintenance required
3-Outofspecication
4 - Warning
5 - Error
Table 25: Device status
10.4.3.5 0x2100 Get Mapping Function
Internal function
10.4.3.6 0x2101 Locating function
Sub-
index
Name Description
Access type
Factory
reset
1 call/cancel Internal büS function
This function enables a device in the system to be located
usingthecontrolsystem.ThetopLEDindicatorwillbriey
starttoashwhenthelocatingfunctionisactivated(fast
ashingLEDs)
0 = activated
1 = deactivated
RW
Table 26: 0x2101 Locating function
10.4.3.7 0x2102 Blockdownload Cong Function
Internal function
english
Type 8691, Rev. 2
