Burkert 8691 - 0 X2 C0 D CMD Set-Point

47
Start-up
Sub-
index
Name Description
Access type Data type Data memory
Factory
reset
0x8 Teach function start
Start teach function:
Function for measuring the stroke,
opening time, closing time and end
positions.
0: Finished (teach function aborted)
1: Start automatic teach function
2: Start manual teach function
RW UINT8
0x9 Is NO
Flag shows pneumatic function
0: Normally closed (NC)
1: Normally open (NO)
RO UINT8
Table 16: 0x2C0C Teach function
10.3.5.9 0x2C0D CMD set-point
Sub-
index
Name Description
Access type Data type Data memory
Factory
reset
0x1 CMD set-point value
source
Select CMD set-point value source:
Congurethesourceofthecontrolsignal
for opening and closing the valve
0: büS/CanOpen
1: IO-Link
2: Internal button (manual)
3: Manual set-point value (see 0x4)
RW UINT8 x x
0x4 Manual CMD setpoint
Select manual set-point value
0: Close
1: Open
RW UINT8
Table 17: 0x2C0D CMD set-point
english
Type 8691, Rev. 2
