Start-up
10.3.4.2 Process output data (PDout)
Length: 1 bytes
Sub-
index
Bit
oset
Length
(bits)
Data type Description
1 0 1 Boolean CMD set-point value
True = Open
False = Closed
2 1 1 Boolean
Locatingfunction(fastashingLEDs)
True = Activated
False = Deactivated
Table 7: Process output data
10.3.5 Non-cyclic parameters (On-Request Data (ISDU))
Data types used
Name IO-Linktype Length
UINT8 UIntegerT 1 bytes
UINT16 UIntegerT 2 bytes
UINT32 UIntegerT 4 bytes
SINT8 IntegerT 1 bytes
SINT16 IntegerT 2 bytes
SINT32 IntegerT 4 bytes
FLOAT32 Float32T 4 bytes
STRING StringT 20 bits
Table 8: Data types used
