Start-up
Sub-
index
Name Description
Access type
Factory
reset
0x6 IsCalibrated
Indicates whether teach function has been successfully
completed
0: Device has not been taught
1: Device has been taught
RO
0x7 TuneState
State of teach function:
Displays the sequence of the phases 0–5 of the teach
function (negative values are indicative of error states fol-
lowing failure of the teach function)
0: Complete
1: Initialization
2:Endposition1(pilotvalveo)
3: End position 2 (pilot valve on)
4: Check stroke
5: Determine switching time
-1: Timeout end position 1
-2: Timeout end position 2
-3: Stroke too small
-4: Error in determining switching time
-5: Abort by SafePos
-6: Abort by user
RO
0x8 StartTune
Start teach function:
Function for measuring the stroke, opening time, closing
time and end positions.
0: Finished (teach function aborted)
1: Start automatic teach function
2: Start manual teach function
RW
0x9 IsNO
Flag shows pneumatic function
0: Normally closed (NC)
1: Normally open (NO)
RO
Table 34: 0x2C0C Teach function
