72
Operation
Valve position Valve position
status, color
Device status: Function control
status, color
Open is lit yellow* blinks alternately orange and yellow*
Half-way is lit white* blinks alternately orange and white*
Closed is lit green* blinks alternately orange and green*
Table 44: Valve mode + errors + warnings, part 2
Valve position Valve position
status, color
Device status: Out of specication
status, color
Open is lit yellow* blinks alternately yellow and yellow*
Half-way is lit white* blinks alternately yellow and white*
Closed is lit green* blinks alternately yellow and green*
Table 45: Valve mode + errors + warnings, part 3
Valve position Valve position
status, color
Device status: Maintenance required
status, color
Open is lit yellow* blinks alternately blue and yellow*
Half-way is lit white* blinks alternately blue and white*
Closed is lit green* blinks alternately blue and green*
Table 46: Valve mode + errors + warnings, part 4
Forerrormessagesandwarningmessages,theLEDsarebrieyswitchedobetweenthechangeofthe
colors.
For localizations, the colors are only shown momentarily.
* Factory setting, selectable colors for the valve position: O, white, green, blue, yellow, orange, red
