Translation of the Original Operating Manual
2.6.2 Instructions
An instruction is composed of a pictogram:
(1) Pictogram contains information regarding
the proper handling of the machine.
The pictogram contains information in an image or
descriptive text or in a table.
Order number and explanation
85180
Attention!
Check oil level regularly.
85203
This pictogram identifies attachment points for fastening lifting
gear that can be used to load and unload the machine onto
and from a load carrier.
Only fasten your lifting gear at / on the identified attachment
points.
88323
Block ball valve securing the open dosing gate against inad-
vertent lowering:
Position lock closed – block ball valve closed
Position lock open – block ball valve open
