Translation of the Original Operating Manual
4.14 Oilcooling
The pump is driven by an electric motor (1), the pump (2) pumps the oil. The Oil-/Aircooler reduce the
temperature and protect against overheating. The level- and temperature switch (4) checks the oillevel
and -temperature. If the oillevel ist o low or the temperature to high, the system stops using the safety
function. The Oilcooling system has an integrated filter (5) which cleans the oil
Abb. 4-25: Overview Oilcooling
Clean all filters and cooling fins daily.
