BVL V-MIX Fix Plus - V-MIX Fix Plus Extended Models

Technical data
V-MIX Fix Plus
Translation of the Original Operating Manual
33
3.2 V-MIX Fix Plus 13-2S to 25-2S
Type
Unit
13-2S
15-2S
15N-2S
17-2S
17N-2S
Capacity
m³
13
14.8
15.4
16.6
17.1
Overall length - mixing hopper
mm
4860
4975
5300
5060
5380
Overall width - mixing hopper
mm
2050
2050
2270
2050
2270
Overall width with one side door
mm
2160
2160
2380
2160
2380
Overall width with two side doors
mm
2260
2260
2480
2260
2480
Machine height with standard features
measured from bottom edge of base plate
(700 mm support frame)
mm
2400
2600
2330
2800
2480
Minimum machine height with standard
features measured from bottom edge of
base plate
(600 mm support frame)
mm
2300
2500
2230
2700
2380
Unladen weight
kg
4900
5300
6000
5500
6330
Type
Unit
20-2S
20H-2S
22-2S
24H-2S
24-2S
Capacity
m³
18.7
19.8
21.5
23.2
23.2
Overall length - mixing hopper
mm
5590
5515
5660
5675
5795
Overall width - mixing hopper
mm
2370
2270
2370
2270
2370
Overall width with one side door
mm
2480
2380
2470
2355
2480
Overall width with two side doors
mm
2580
2480
2600
2485
2580
Machine height with standard features
measured from bottom edge of base plate
(700 mm support frame)
mm
2500
2730
2640
3030
2870
Minimum machine height with standard
features measured from bottom edge of
base plate
(600 mm support frame)
mm
2400
2630
2540
2930
2770
Unladen weight
kg
6850
6550
7050
6675
7150
