BVL V-MIX Fix Plus - Illustrations Used

User information
8
Translation of the Original Operating Manual
V-MIX Fix Plus
Fig. 1-1
(1) Front side (drive side)
(3) Rear side
(2) Left side
(4) Right side
1.4 Illustrations used
Instructions for actions and responses
Actions that need to be carried out following a specific sequence are identified as numbered instructions
for action.
Strictly adhere to this order. In certain cases, the result of the instruction for action will be marked with an
arrow.
Example:
1. Instruction for action 1
→ Result of instruction for action 1
2. Instruction for action 2
Lists
Unordered lists are displayed as lists with bullet points.
Example:
 Item 1
 Item 2
Item numbers in illustrations
Figures included in round brackets refer to the item numbers included in the adjoining illustration.
Example (1)
1
2
