C-Data FD1216S User Manual

Company Address: Flat 6, Bldg 4,South 2 of Honghualing Industrial Zone,Liuxian Road, Xili Town, Shenzhen, Guangdong, China(518055)
Tel: +86-755-26014509/4710/4711 Fax:+86-755-26014506
Website: www.cdatatec.com
39
【Command】
showvlanall
showvlanvlan‐id
【View】Viewconfig
【Parameter】all：CheckingallexistingVLANinformation
vlan‐id：VLANID，UsedtoidentifyauniqueVLAN.
【Description】
ThiscommandisusedtoqueryforallexistingVLAN,orqueriesaspecifiedVLAN,thusobserving
theVLAN
whichcontainsportsandportstagprocessingmode
【Example】
CheckingtheinformationofVLAN100.
OLT(config)#showvlan100
‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐   
VLANTagged‐PortsUntagged‐Ports
 ‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐   
100p1‐p8xge1

8.3vlanmode
【Command】
vlanmodeport‐listmode
【View】viewge;viewEPON;viewxge;viewlink‐aggregation.
【Parameter】
port‐list
： To‐be‐setportlistofmodelVLAN.
mode：modelvlan;containsmodelaccess、modelhybrid、modeltrunk.
【Description】
Accessmodeonlyallowuntaggedpacketstoenter,andattachingnativeVLANportforuntagged,
the messages which come from port will be peeling off the label. Trunk mode allows
 multiple
messageswithdifferentlabeltoenter,whichbaseonthelabelofmessageexistintrunklist.Out
messagekeep original label. Hybrid mode is a collection of access or trunk mode, hybrid mode
portallowsmultiplemessageswithdifferentlabelintoandoutofmessageyoucanset
thelabel
orkeeppullingofflabels.
【Example】
TosettheOLTge1portadtrunkmodel.将 OLTge1
OLT(interface‐ge)#vlanmode1trunk

8.4vlanaccess
【Command】
vlanaccessport‐listvlan‐id
【View】viewge;viewEPON;viewxge;viewlink‐aggregation.
