CALREC Putting Sound in the Picture 193
• EQ strip controls have been re-
arranged to be more usable.
• Changes to delay unit defaults can be
applied to all existing paths.
• H2O can select and overwrite patches
made by consoles.
• CSCP interface information is
displayed in the External Control
screen (main application).
• Source and Destination Protection
now covers channel input1 / input2
switching.
V1.14.1
• Replay has been added to allow input 1
to input 2 switching for a definable set
of channels.
• Non-Motorised VCA Slave operation
has been added as a preference.
• Channel PFLs can now be activated
via GPI.
• Trim controls for inputs 1 and 2 can
now be linked per channel.
• Surface layouts can now be defined
and saved by the user on the fly.
• The range of available compressor
ratios has been increased.
• Each path’s Cut status is now indicated
on its output meter.
V1.14.2
• More path properties can be copied
(Input, Fader, Downmix, Delay, Direct
Outputs) and it’s now possible to copy
between different path types.
• The oscillator can produce a tone
sweep and each leg of the oscillator
can be cut.
• H2O can control SRC, 48V and Gain
on Hydra2 sources.
• The current sync source is visible at all
times in the main application footer.
• Group PFL and cut can be controlled
remotely through GPIs.
• A new meter scale is available with
markers and colour changes at -12 and
-18 dBFS.
• The direct output setup process has
been improved:
* Tapping an empty direct output
control now brings up the direct
output setup dialogue.
* The direct output feed can be
chosen during setup (Pre EQ,
Pre Fader, Post Fader, Mix Minus).
* The assigned path can be routed
to the mix minus bus in the direct
output setup dialogue.
• The Focus Area in Sends-Routes and
Outputs modes has been improved
* The display of which send or output
is in focus is much clearer.
* Any adjustment to a send or output
will put it in focus.
• Minor updates to surface graphics to
improve clarity.
• Aliases can be created for Hydra2
Patchbays.
• Dual router cores can now be used as
slave routers.
• Support for MY5792 v2.08.
V1.14.5
• CSCP override by fader touch.
• Talkback to Misc. Monitors can be
configured to dim or cut Main LS O/P.
V1.14.6
• Each console core has a unique
MAC for each control processor card
allowing connection of several control
processor cores to a LAN.
V1.14.7
• Look ahead limiter on Main bus
outputs.
V1.14.8
• SNMP agent can be configured to
send System Status messaging to
multiple SNMP servers for redundancy.
V1.16
• Auto promotion of slave routers.
V1.16.1
• The new Dante modular I/O card is
now supported, providing an interface
between Dante and Hydra2 networks.
• New COM express-based control
processors are now supported
for Artemis Light systems due to
obsolescence.
• Talkback to Misc Monitors can now be
inhibited either fully or in conjunction
with Mic Open systems.
• PFL overpress can now be disabled
from the main application.
• DPP Live and DPP non-Live settings
are now available for loudness meters.
•
V3.0 for New Concord Processors
• New Processing Mode for simplified
access to EQ, Dyn, Automixers,
Delay & AutoFaders.
• Refined Modes and Layers switching
for simplified navigation.
• Presets, which are snapshots of a
path’s parameter settings, can be
created, backed up and restored.
• New Wilds mode allows user to config
custom controls within the assign
panels.
• Pre-v3.0 Wilds mode now known as
Strips.
• Patching screen redesigned to show
connected destinations for each
source.
• New Path Based AutoFader system
with full control over delay duration and
level for fade in and fade out.
• Multi- layer interrogate: allows user to
see all contributing paths across layers
• Spill controls can now access and
control stereo signal’s left and right
legs independently.
• Additional Meter Scales for more
regional requirements.
• Tone output available to output ports.
• EMBER control of input source
settings.
• GPO available for triggering playout
devices from fader open AND on.
• Mic/Line gain: display now shows
highest and lowest value if the gain is
not the same on all channel legs.
• Trim gain: display now shows highest
and lowest value if the gain is not the
same on all channel legs.
• New Waves Soundgrid modular I/O
card available providing an interface
between Waves Soundgrid Plug-in
Server and Hydra 2.
• Allows creation of Input Aliases for
Hydra2 Patchbays.
• User Logging.
