72 ARTEMIS Digital Broadcast Production Console Processing Audio
Frequency
Each band has a full frequency range
from 20Hz to 20kHz. This is controlled by
the 2nd Control cell row from the bottom.
Response
Pressing the RESP button for any band
in the top row of Control cells allows
the rotary control to scroll through the
available response types. The button
will be lit during this process. Once
the response has been chosen it can
be selected by pressing the button a
second time. When the RESP button is
not pressed, the rotary doubles as the Q
control. Fig 2 shows the Response Types
and parameters.
EQ curve display
The TFT touchscreen above the Control
cells shows a graphical representation
of the current EQ curve for the assigned
channel with it’s band markers, numerical
values and response type.
Note that a thumbnail view of the EQ
curve is also made available in the
PROCESSING-EQ button cell selector.
RESP Gain Range Q or dB/octave
High Pass Filter
N/A 12 dB/octave
Low Shelf
+18dB to -18dB Variable 6dB/octave
Notch
-30dB Fixed 22.2
Higher Mid
Frequency Bell
+18dB to -18dB Variable 0.3 to 10
Lower Mid
Frequency Bell
+18dB to -18dB Variable 0.3 to 10
High Shelf
+18dB to -18dB Variable 6dB/octave
Low Pass Filter
N/A 12 dB/octave
FIG 2 - EQ RESPONSE TYPES AND PARAMETERS
