CAME FERNI User Manual

9
SITE PREPARATION
INSTALLATION MUST BE PERFORMED BY AN EXPERT QUALIFIED PERSONNEL AND IN FULL COMPLIANCE WITH
CURRENT REGULATIONS. Gate must be constructed and installed according to ASTM F2200 standards.
Before installation, perform the following:
1
Make sure you have a suitable omnipolar cut-off device with contacts more than 1/32” in (3 mm) apart, and independent (sectioned off) power supply.
2
Make sure the structure of the gate is sturdy, the hinges work and that there is no friction between moving and non-moving parts.
3
Check that any connections inside the container (that provide continuity to the safety circuit) are fitted with additional insulation compared to other internal live parts.
4
Make sure you have suitable tubing and conduits for the electrical cables to pass through and be protected against mechanical damage.
TOOLS AND MATERIALS + WIRING CHART + SITE PREPARATION
TOOLS AND MATERIALS
Make sure you have all the tools and materials required for the installation. The
installation should be completed in accordance with all national and local standards
and regulations.
The following tools may be needed for your installation:
PREPARATION
• Drill and Drill Bits
• Hack Saw
• Tape Measure
• Pliers
• Screwdrivers
• Shears
• Level
CONNECTION Cable length 3-32 ft. Cable length 32-65 ft. Cable length 65-98 ft.
120 V control panel power supply 3G x 14AWG 3G x 14AWG 3G x 10AWG
24 V motor power supply 2G x 14AWG 2G x 14AWG 2G x 10AWG
Flashing light 2 x 14AWG 2 x 14AWG 2 x 14AWG
Photocell transmitters 2 x 24AWG 2 x 24AWG 2 x 24AWG
Photocell receivers 4 x 14AWG 4 x 14AWG 4 x 14AWG
Accessories power supply 2 x 24AWG 2 x 24AWG 2 x 18AWG
Command and safety devices 2 x 24AWG 2 x 24AWG 2 x 24AWG
Antenna connection max. 65 ft.
Encoder connection max. 98 ft.
NOTE: If the length of the wire differs from that specified in the table, then you must determine the proper wire gauge based on the actual power draw of the devices
connected and the local electrical codes. For connections that require several, sequential loads, the sizes provided in the table must be re-evaluated based on actual power
draw and distances. When connecting products that are not specified in this manual, refer to the instructions provided with said products.
NOTE: Use copper conductors only.
WIRING CHART
Cable list and minimum thickness

CAME FERNI Specifications

General

Max Gate Weight	800 kg
Power Supply	230 V AC
Motor Power	300 W
Operating Temperature	-20°C to +55°C
Protection Rating	IP54
Duty Cycle	30%
Maximum Leaf Weight	800 kg
Safety Features	Obstacle detection
