CAME FERNI

31
2
3
7
11
12
18
10
1
1
4
13
4
15
16
17
9
8
5
6
11
14
19
REPAIR PARTS
Item Description Part Number
1 Lock Cylinder 119RIBX042
2 Drive Arm 119RID076
3 Gate Bracket 119RID077
4 Gearmotor Box 119RID080
5 Second Reduction Shaft 119RID089
6 First Reduction Shaft 119RID090
7 Release Lever 119RID156
8 Slow Shaft 119RID356
9 Transmission Arm 119RID357
10 Release Cover 119RID358
11 Lateral Plugs 119RID359
12 Cover 119RID360
13 Operator Mounting Plate 119RID361
14 Support Link 119RID362
15 Limit Switch Assembly 119RID363
Item Description Part Number
16 Cam Stop 119RID364
17 Release Bar 119RID365
18 Worm Gear 119RID385
19 Motor 119RID386
NOT SHOWN
Hardware Bag 119RID366
Control Panel- case only 119RTR375
Transformer 119RIR374
Electronic card (ZLJ24U) 3199ZLJ24U
Security✚ 2.0™ Radio Card AF43CH
