23
Radio Card Slot
Electronic Card
INSTALL AND PROGRAM THE SECURITY+ 2.0™ RADIO CARD
PROGRAMMING
Display
ENTER Button
ERASE THE SECURITY+ 2.0™ RADIO CARD MEMORY
1
Press and hold the button on the Security+ 2.0™ radio card until the LED
goes out (approximately 6 seconds). The memory is now erased.
NOTICE: This device complies with Part 15 of the FCC rules and Industry Canada (IC) licence-exempt RSS-210. Operation is subject to the
following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the
equipment.
This Class B digital apparatus complies with Canadian ICES-003.
INSTALL AND PROGRAM THE
SECURITY+ 2.0™ RADIO CARD
1
Disconnect all power to the operator.
2
Insert the Security+ 2.0™ radio card into the slot on the electronic card.
3
Connect power.
NOTE: The electronic card picks up the Security+ 2.0™ radio card when the
operator is powered up.
4
Press the button on the Security+ 2.0™ radio card (the LED will light).
5
Press the button on the remote control (the LED on the radio card will go out
if programming is successful).
6
Activate the display menu by holding the ENTER button for one second.
7
Navigate to USERS > Add User > Choose Confirm? (yes).
8
From the Related Func. menu choose the desired function (2-7, Open,
B1-B2, 2-3P, or Disabled) and then press the ENTER button to make the
selection. The menu will display "Waiting Code".
9
While the "Waiting Code" is displayed, press and hold the remote control
button. The display will flash the code and then exit to the Add User menu
indicating programming is complete.
To program additional remote controls follow steps 4 and 5 above only.
