* The labels No. 11, 12 and 13 are different in a kind and the number of sheets by the type of DADF. Refer to the following table to confirm them.
T-2-1
[1] DADF main unit 1 unit [8] Stepped screw (M4X10) 2 pcs.
[2] Hinge cover 2 pcs. [9] Binding screw (M3X6) 1 pc.
[3] Glass positioning plate 1 pc. [10] Flat head screw (M4X6) 1 pc.
[4] Glass holder 1 pc. [11]* Finger pinch caution label 1 1 pc.
[5] Stream reading glass 1 pc. [12]* Finger pinch caution label 2 1 pc.
[6] Face sticker 2 pcs. [13]* Glass cleaning/lamp caution label 1 pc.
[7] Stepped screw (M5X6) 2 pcs.
INCH/A type A type INCH/AB/K type
[11] Finger pinch caution label 1 [A] --- Yes Yes
[B] Yes --- Yes
[12] Finger pinch caution label 2 [C] --- Yes Yes
[D] Yes --- Yes
[13] Glass cleaning/lamp caution label [E] --- --- Yes
[F] --- Yes ---
[G] Yes --- ---
[H] --- --- Yes
