3.2.4 Forward Pickup/Reverse Delivery (Double-sided Document -> Duplex Printing) Operation
0024-6987
The document flows as shown below.
Duplex read operation (when two document sheets are placed)
F-3-5
MEMO:
This operation is performed for all double-sided documents irrespective of whether document widths are the same
or different.
Pickup and formation of loop of
first document sheet
Waiting for reading of
the first document
Start of reading of front side of
first document sheet
End of reading of first
document sheet
Stop after feeing the first document
sheet to reversal position
Document
To next page
To Next Page
