Canon imageCLASS LBP121dn - Names of Parts and Their Functions

Names of Parts and Their Functions
95LW-004
Fr
ont Side
Check these parts on the front when operating the machine.
Front Side(P. 8)
● Use the oper
ation panel to operate the machine and congure the settings.
Operation Panel(P. 10)
● Load printing paper into the paper dr
awer.
Paper Drawer(P. 12)
Rear Side
Check the r
ear parts when installing and connecting the machine and when clearing paper jams.
Rear Side(P. 9)
About the Machine
7
