Canon imageCLASS LBP121dn - Configuring the Default Settings (Setup Guide)

388 pages

Save Page as PDF

To Next Page

To Previous Page

Algorithm TLS Version

TLS 1.3 TLS 1.2 TLS 1.1 TLS 1.0

AES-CBC (128bit)

AES-GCM (256bit)

AES-GCM (128bit)

3DES-CBC

CHACHA20-POLY1305

Key Exchange Algorithm

RSA

ECDHE

X25519

Signature Algorithm

RSA

ECDSA

HMAC Algorithm

SHA1

SHA256

SHA384

About the Machine
