5. Remove the Main Drive Unit.
4x
2x
CAUTION:
Points to Note at Assembly
When installing the Main Drive Unit, be sure that the shafts of the 3 gears are fitted in the holes [A] on the Main Drive Unit.
[A]
Removing the Cassette Pickup Unit
■ Preparation
1. Remove the cassette.
