Basic Configuration
Functional Configuration
Description
This machine is roughly composed of the following five blocks.
• Laser Exposure System
• Controller System
• Image Formation System
• Pickup / Feed System
• Fixing System
Image Formation System
L
aser Exposure System
Drum
Laser scanner
Duplex Feed System
Main
controller
DC
controller
Controller System
Laser beam
Paper flow（simplex）
Paper flow（duplex）
Signal flow
Pickup/Feed system
Fixing System
Manual feed
pickup unit
Delivery
assembly
Fixing
assembly
Pickup
unit
Cassette
