Drive Configuration

SL2

SL1

SL3

CL2

Symbol Name

M1 Main Motor

M2 Pickup Motor

M4 Lifter Motor

CL2 Duplex Re-pickup Clutch

SL1 Cassette Pickup Solenoid

SL2 Duplex Reverse Solenoid

SL3 Multi-purpose Tray Pickup Solenoid
