List of Items Which Can Be Imported
The following shows the items to be imported for this model.
Note that the setting values are not imported in cases such as below:
• Items which are originally not included in a DCM file (e.g.:"Settings/Registration Basic Information" of a DCM file exported
using service mode)
• Not included in the import coverage (Cases A to C)
• There are no options and functions related to setting values
The import coverage shown in the table below is as shown below. Those that are not described here cannot be imported.
Import coverage Description
Case A: The same machine Import to the same machine (for backup and restoration, etc.)
Case B: The same model Import to a different machine of the same model (the same series)
Case C: Different model Import to a different machine of a different model (a different series)
Service Mode Items Which Can Be Imported
The service mode items that can be imported using the DCM function are described below.
Initial screen Large Small Case A Case B Case C
ADJUST GR.
CHARGE BIAS K Yes - -
DEV BIAS K Yes - -
FRT FUSE TEMP Yes - -
SUBTLE DENSITY CORR. Yes - -
Special Grad.Process Yes Yes -
LASER BRIGHT K Yes - -
OPTION GR.
B4-L-CNT Yes Yes -
COUNTER-SW Yes Yes -
CRG LIFE STEP Yes Yes -
CRG LIFE STOP Yes Yes -
CHANGE CRG WARN LV Yes Yes -
SLEEP SETTINGS Yes Yes -
RMT-SW Yes Yes -
MPT 2-Sd (1st Side) Yes Yes -
Img Calibration Mode Yes Yes -
FUNCTION GR.
USB-H Yes Yes -
MEAP
MEAP FUNCTION Yes Yes -
DDNSINTY Yes Yes Yes
IPMTU Yes Yes Yes
PDL Z Logic Yes Yes -
FILE BOX FUNC. Yes Yes -
LOG GR.
SYSTEM LOG Yes Yes -
LOGGING UTILITY Yes Yes -
DEBUGLOG-SW Yes Yes -
DEBUGLOG-MODE Yes Yes -
PANEL LOCK GR.
PANEL LOCK Yes Yes -
NETWORK GR.
DNSTRANS Yes Yes Yes
JOB SERIALIZE Yes Yes Yes
List of Items Which Can Be Imported
239
