Controller System
Configuration/Function
This product is mainly controlled by the main and DC controllers.
No. Parts name Function
[1] Main Controller PCB Provides controls on the system, image processing and network and maintain various
setting values.
[2] DC Controller PCB Provides controls on printer, laser, high-voltage , I/O, etc. and maintain setting values.
