Controller System
Removing the Controller Cover
■ Preparation
1. “Removing the Rear Cover Unit” on page 127
2. Remove the cassette.
3. “Removing the Cartridge” on page 127
4. “Removing the Right Cover Unit” on page 129
■ Procedure
1. Remove the Controller Cover.
Removing the Main Controller PCB
■ Preparation
CAUTION:
“Before Replacing the Main Controller PCB” on page 178
1. “Removing the Rear Cover Unit” on page 127
2. Remove the cassette.
3. “Removing the Cartridge” on page 127
4. “Removing the Right Cover Unit” on page 129
5. “Removing the Controller Cover” on page 140
