This example illustrates how to rotate an A4 (210.0×297.0 mm)/Letter (8.3×11.7 in) original in portrait orientation 90 de-
grees to fit within the width of A3/A4 roll paper (297.0 mm [11.7 in]), which enables you to conserve paper.
1. Choose Print in the application menu.
2. Select
the printer in the dialog box, and then open the printer driver dialog box.(See "Accessing the Printer Driver
Dialog Box from Applications (Windows)
→P.211 ")
3. Make sure the Main sheet is displayed.
4. In the A Media Type list, select the type of paper that is loaded. In this case, click Plain Paper.
Enhanced Printing Options
>
Conserving roll paper
>
Conserving Roll Paper by Rotating Originals 90 Degrees (Windows) iPF815
3
168
