Canon imagePROGRAF iPF815 User Manual

Output Method dialog box
The Output Method dialog box allows you to select the Output Method and set the save settings when saving to the box.
Note
• To display the Output Method dialog box, on the Page Setup sheet, click Output Method. (Refer to "Page
Setup Sheet →P.228 ")
A Output Method
If Print is selected, the print job is saved to the printer hard disk after printing has finished.
If Print (auto delete) is selected, the data is deleted immediately after printing has finished.
If Save in mail box is selected, the print job is saved to the printer hard disk. If you choose Save in mail box, also specify
the destination personal box in the Mail box list.
If the Save data before printing check box is selected, printing starts after the print job has finished being saved in the
temporary save box.
B Name of data to be saved
To use the file name, choose Use file name.
Otherwise choose Enter name and enter a name in Name.
C Mail box
Displays a list of mail boxes. If you choose Save in mail box, also specify the destination personal box from the list.
Windows Software
> Printer Driver >
iPF815 Output Method dialog box
4
231

Canon imagePROGRAF iPF815 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Pigment matte black, Yellow
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	5
Package weight	301200 g
Bundled software	Printer Driver Extra Kit for Windows/Mac (Free Layout, Color imageRUNNER Enlargement Copy, Advanced Preview), Print Plug-in for Microsoft Word/Excel/PowerPoint for Windows, Digital Photo Front-Access for Windows, PosterArtist Lite for Windows
Media thickness	0.07 - 0.8 mm
Roll top margin	3 mm
Maximum print size	-
Maximum roll length	18 m
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A0, A1
ISO B-series sizes (B0...B9)	B0, B2
Electromagnetic compatibility	RoHS Directive, WEEE, Executive Order (USA)
Power requirements	AC 100 - 240V, 50/60Hz
Power consumption (off)	1 W
Power consumption (standby)	6 W
Power consumption (typical)	190 W
Certification	UL (USA), C-UL (Canada), S mark (Argentina), CE mark (EN60950, EN55022 classB, EN61000-3-2, EN-61000-3-3, EN55024) (EU), CB certification (Others), FCC Class B (USA), IC Class B (Canada)
Storage media	HDD
Internal storage capacity	160 GB
Sound power level (standby)	35 dB
Sound pressure level (printing)	52 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10/100Base-T/TX Mbit/s
Sustainability certificates	ENERGY STAR
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Compatible operating systems	Windows XP (32/64 bit), Server 2003 (32/64 bit), Server 2008 (32/64 bit), Windows Vista (32/64 bit), Windows 7 (32/64 bit); Macintosh OS X 10.3.9 - 10.6 (32 bit), OS X 10.5 - 10.6 (64 bit)

Weight and Dimensions

Dimensions (WxDxH)	1892 x 975.4 x 1143 mm
