Canon imagePROGRAF iPF815 User Manual

Cause Corrective Action
Highly transparent film is loa-
ded that cannot be used for au-
tomatic feed amount adjust-
ment.
Press the Online button to clear the error, and then adjust the feed amount manually.
(See "Manual Band Adjustment (Manual Band Adj).") →P.678
PHead needs cleaning.
Cause Corrective Action
The Printhead nozzles
are clogged.
Press the Online button to resume printing.
Follow these steps to clean the Printhead.
1. Hold down the Stop button for a second or more to cancel printing.
2. Printhead cleaning options.
(See "Cleaning the Printhead.") →P.819
If the message is still displayed after you execute Head Cleaning B once or twice, contact
your Canon dealer for assistance.
Wrong printhead.
Cause Corrective Action
An incompatible Printhead has been installed. Open the Top Cover and replace the Printhead with a new one.
(See "Replacing the Printhead.") →P.820
Problem with Printhead
Cause Corrective Action
The Printhead nozzles are becoming clogged. If printing is faint, clean the Printhead.
(See "Cleaning the Printhead.") →P.819
Printhead error
Cause Corrective Action
There is a problem with the Printhead. Open the Top Cover and replace the Printhead with a new one.
(See "Replacing the Printhead.")
→P.820
No printhead
Cause Corrective Action
No Printhead is installed. Install the Printhead.
(See "Replacing the Printhead.") →P.820
Error Message
> Messages regarding printheads >
PHead needs cleaning. iPF815
13
910

Canon imagePROGRAF iPF815 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Pigment matte black, Yellow
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	5
Package weight	301200 g
Bundled software	Printer Driver Extra Kit for Windows/Mac (Free Layout, Color imageRUNNER Enlargement Copy, Advanced Preview), Print Plug-in for Microsoft Word/Excel/PowerPoint for Windows, Digital Photo Front-Access for Windows, PosterArtist Lite for Windows
Media thickness	0.07 - 0.8 mm
Roll top margin	3 mm
Maximum print size	-
Maximum roll length	18 m
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A0, A1
ISO B-series sizes (B0...B9)	B0, B2
Electromagnetic compatibility	RoHS Directive, WEEE, Executive Order (USA)
Power requirements	AC 100 - 240V, 50/60Hz
Power consumption (off)	1 W
Power consumption (standby)	6 W
Power consumption (typical)	190 W
Certification	UL (USA), C-UL (Canada), S mark (Argentina), CE mark (EN60950, EN55022 classB, EN61000-3-2, EN-61000-3-3, EN55024) (EU), CB certification (Others), FCC Class B (USA), IC Class B (Canada)
Storage media	HDD
Internal storage capacity	160 GB
Sound power level (standby)	35 dB
Sound pressure level (printing)	52 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10/100Base-T/TX Mbit/s
Sustainability certificates	ENERGY STAR
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Compatible operating systems	Windows XP (32/64 bit), Server 2003 (32/64 bit), Server 2008 (32/64 bit), Windows Vista (32/64 bit), Windows 7 (32/64 bit); Macintosh OS X 10.3.9 - 10.6 (32 bit), OS X 10.5 - 10.6 (64 bit)

Weight and Dimensions

Dimensions (WxDxH)	1892 x 975.4 x 1143 mm
