*When using the Media Take-up Unit, either hold down the Stop button for a second or more to cancel printing or
press the Online button to continue printing. However, if you continue printing, the roll paper may run out dur-
ing the print job and you may not be able to print all of the document.
This paper cannot be used.
Cause Corrective Action
Paper that is too large for the printer has been
loaded.
Lift the Release Lever and load paper of the correct size.
(See "Paper Sizes.") →P.620
Paper that is too small for the printer has been
loaded.
Lift the Release Lever and load paper of the correct size.
(See "Paper Sizes.") →P.620
Paper has been loaded that is too small to print
the test pattern for printhead adjustment or noz-
zle checking.
Lift the Release Lever and load unused paper A4 or larger. More
than one sheet may be required depending on the adjustment.
Roll printing is selected.
Cause Corrective Action
You have attempted to print a job sent from a computer or a test
print sheet or other printer status information on a roll, but no roll is
loaded.
Load a roll and try printing again.
To print on a sheet instead, hold down the Stop
button for more than a second to cancel printing,
load a sheet, and then print.
(See "Loading and Printing on Sheets.")
→P.8
Roll printing is selected, but sheets are loaded.
Cause Corrective Action
A print job for rolls was received when a sheet is
loaded.
Follow these steps to load and print on a roll.
1. Press the OK button and remove the sheet.
(See "Removing Sheets.") →P.656
2. Load a new roll.
(See "Loading Rolls in the Printer.") →P.628
The printer now starts printing the print job.
Hold down the Stop button for a second or more to cancel printing.
The roll is empty.
"Lift the release lever and replace the roll."
Cause Corrective Action
The roll is empty. Follow these steps to replace the used roll with a new roll
of the same type and size.
Error Message
> Messages regarding paper >
iPF815 This paper cannot be used.
13
897

Canon imagePROGRAF iPF815 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Pigment matte black, Yellow
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	5
Package weight	301200 g
Bundled software	Printer Driver Extra Kit for Windows/Mac (Free Layout, Color imageRUNNER Enlargement Copy, Advanced Preview), Print Plug-in for Microsoft Word/Excel/PowerPoint for Windows, Digital Photo Front-Access for Windows, PosterArtist Lite for Windows
Media thickness	0.07 - 0.8 mm
Roll top margin	3 mm
Maximum print size	-
Maximum roll length	18 m
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A0, A1
ISO B-series sizes (B0...B9)	B0, B2
Electromagnetic compatibility	RoHS Directive, WEEE, Executive Order (USA)
Power requirements	AC 100 - 240V, 50/60Hz
Power consumption (off)	1 W
Power consumption (standby)	6 W
Power consumption (typical)	190 W
Certification	UL (USA), C-UL (Canada), S mark (Argentina), CE mark (EN60950, EN55022 classB, EN61000-3-2, EN-61000-3-3, EN55024) (EU), CB certification (Others), FCC Class B (USA), IC Class B (Canada)
Storage media	HDD
Internal storage capacity	160 GB
Sound power level (standby)	35 dB
Sound pressure level (printing)	52 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10/100Base-T/TX Mbit/s
Sustainability certificates	ENERGY STAR
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Compatible operating systems	Windows XP (32/64 bit), Server 2003 (32/64 bit), Server 2008 (32/64 bit), Windows Vista (32/64 bit), Windows 7 (32/64 bit); Macintosh OS X 10.3.9 - 10.6 (32 bit), OS X 10.5 - 10.6 (64 bit)

Weight and Dimensions

Dimensions (WxDxH)	1892 x 975.4 x 1143 mm
