Canon imagePROGRAF iPF815 User Manual

Preview
The Features of Preview ................................................................................................................................. 243
Operating Environment ................................................................................................................................... 243
Starting Preview .............................................................................................................................................. 243
Preview Main Window ..................................................................................................................................... 245
Dialog Area ...................................................................................................................................................... 248
Enlarge/Reduce the screen display ................................................................................................................. 249
Moving a Page ................................................................................................................................................ 249
Using the ruler ................................................................................................................................................. 250
Priority setting for rotating 90 degrees ............................................................................................................ 250
Printing with Selecting the Layout ................................................................................................................... 252
Print on the Center .......................................................................................................................................... 254
Not Print Spaces at the Top/Bottom ................................................................................................................ 255
The Features of Preview
The main features of Preview are as follows.
• While viewing this screen, you can adjust layout settings of a document created with application software.
• You
can not only adjust layout settings but also your changes will be instantly applied on the preview screen, and you
can print the preview screen as it is seen.
Note
• The
media type, image size, detailed media settings, and the printer settings can cause the actual print output
to differ from the Preview settings.
Operating Environment
You can use the Preview in the following environments.
• Compatible Operating System
Windows 2000, Windows XP, Windows Server 2003, Windows Vista, Windows Server 2008, Windows 7
• Software that requires installation
imagePROGRAF Printer Driver
Starting Preview
Follow the procedure below to start the Preview.
1. Start the apllication software which you use.
2. From the application software's File menu, select the printer setup menu to open the Print dialog box.
Note
• Normally, select Print from the File menu.
Windows Software
> Preview >
iPF815 The Features of Preview
4
243

Canon imagePROGRAF iPF815 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Pigment matte black, Yellow
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	5
Package weight	301200 g
Bundled software	Printer Driver Extra Kit for Windows/Mac (Free Layout, Color imageRUNNER Enlargement Copy, Advanced Preview), Print Plug-in for Microsoft Word/Excel/PowerPoint for Windows, Digital Photo Front-Access for Windows, PosterArtist Lite for Windows
Media thickness	0.07 - 0.8 mm
Roll top margin	3 mm
Maximum print size	-
Maximum roll length	18 m
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A0, A1
ISO B-series sizes (B0...B9)	B0, B2
Electromagnetic compatibility	RoHS Directive, WEEE, Executive Order (USA)
Power requirements	AC 100 - 240V, 50/60Hz
Power consumption (off)	1 W
Power consumption (standby)	6 W
Power consumption (typical)	190 W
Certification	UL (USA), C-UL (Canada), S mark (Argentina), CE mark (EN60950, EN55022 classB, EN61000-3-2, EN-61000-3-3, EN55024) (EU), CB certification (Others), FCC Class B (USA), IC Class B (Canada)
Storage media	HDD
Internal storage capacity	160 GB
Sound power level (standby)	35 dB
Sound pressure level (printing)	52 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10/100Base-T/TX Mbit/s
Sustainability certificates	ENERGY STAR
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Compatible operating systems	Windows XP (32/64 bit), Server 2003 (32/64 bit), Server 2008 (32/64 bit), Windows Vista (32/64 bit), Windows 7 (32/64 bit); Macintosh OS X 10.3.9 - 10.6 (32 bit), OS X 10.5 - 10.6 (64 bit)

Weight and Dimensions

Dimensions (WxDxH)	1892 x 975.4 x 1143 mm
