Page #416 background imageLoading...
Page #416 background image
Jobs on Printer
This shows a list of the print jobs currently held on printers.
You can change the number of jobs displayed per page using the Print Jobs Shown Per Page setting in the View menu or
the toolbar.
You can skip to a particular page using the Go to option in the View menu or the toolbar.
Note
For printers with built-in hard disks, you can view up to 500 print jobs per printer.
For printers without built-in hard disks, you can view up to 32 print jobs per printer. However, only 10 jobs
can be displayed if the printer is switched off.
Regularly Acquired Jobs
This shows a list of regularly acquired print jobs.
To view all the jobs in a set period, specify the period using Period and then Starting Date (or Starting Day of Week or
Starting Month) in the View menu or the toolbar.
For example, to view monthly job logs starting on the 1st of each month, set Period to Monthly and set Starting Date to 1.
Note
Up to 10,000 regularly acquired jobs are displayed for each printer.
Exporting Print Job Data as a CSV File
You can export the collected print job data in the form of a CSV file by selecting Export Job Cost Data in the File menu.
Note
You can also select Export Job Cost Data using the icon in the toolbar.
Selected Jobs
Exports the data for the selected print jobs in the job list as a CSV file.
Note
You can select multiple jobs by holding down the Shift key or Ctrl key as you click the job names.
Listed Jobs
Exports the data for the print jobs currently displayed in the list as a CSV file.
Showing Job Properties
If you select a job in the job list and then select Show Job Properties in the File menu, the Job Properties dialog box
appears, allowing you to check information such as detailed cost data.
You can copy text-based information in this dialog box to the clipboard by clicking the Copy button.
Windows Software
>
Accounting
>
Exporting Print Job Data as a CSV File iPF815
4
400

Table of Contents

Other manuals for Canon imagePROGRAF iPF815

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Canon imagePROGRAF iPF815 and is the answer not in the manual?

Canon imagePROGRAF iPF815 Specifications

General IconGeneral
ColorYes
Printing colorsBlack, Cyan, Magenta, Pigment matte black, Yellow
Maximum resolution2400 x 1200 DPI
Number of print cartridges5
Package weight301200 g
Bundled softwarePrinter Driver Extra Kit for Windows/Mac (Free Layout, Color imageRUNNER Enlargement Copy, Advanced Preview), Print Plug-in for Microsoft Word/Excel/PowerPoint for Windows, Digital Photo Front-Access for Windows, PosterArtist Lite for Windows
Media thickness0.07 - 0.8 mm
Roll top margin3 mm
Maximum print size-
Maximum roll length18 m
Maximum roll diameter150 mm
ISO A-series sizes (A0...A9)A0, A1
ISO B-series sizes (B0...B9)B0, B2
Electromagnetic compatibilityRoHS Directive, WEEE, Executive Order (USA)
Power requirementsAC 100 - 240V, 50/60Hz
Power consumption (off)1 W
Power consumption (standby)6 W
Power consumption (typical)190 W
CertificationUL (USA), C-UL (Canada), S mark (Argentina), CE mark (EN60950, EN55022 classB, EN61000-3-2, EN-61000-3-3, EN55024) (EU), CB certification (Others), FCC Class B (USA), IC Class B (Canada)
Storage mediaHDD
Internal storage capacity160 GB
Sound power level (standby)35 dB
Sound pressure level (printing)52 dB
USB connectorUSB Type-A
USB 2.0 ports quantity1
Ethernet LAN data rates10/100Base-T/TX Mbit/s
Sustainability certificatesENERGY STAR
Operating temperature (T-T)15 - 30 °C
Operating relative humidity (H-H)10 - 80 %
Compatible operating systemsWindows XP (32/64 bit), Server 2003 (32/64 bit), Server 2008 (32/64 bit), Windows Vista (32/64 bit), Windows 7 (32/64 bit); Macintosh OS X 10.3.9 - 10.6 (32 bit), OS X 10.5 - 10.6 (64 bit)
Weight and Dimensions IconWeight and Dimensions
Dimensions (WxDxH)1892 x 975.4 x 1143 mm
