Canon imagePROGRAF iPF815 User Manual

Network Setting (Mac OS X)
Configuring the Printer Driver Destination ...................................................................................................... 793
Configuring the Printer's AppleTalk Network Settings ..................................................................................... 793
Configuring the Destination for AppleTalk Networks ...................................................................................... 794
Configuring the Destination for TCP/IP Network ............................................................................................ 797
Configuring the Destination for Bonjour Network ........................................................................................... 800
Configuring the Printer Driver Destination
Specify the printer driver destination as follows if the printer's IP address is changed, or if you will use the printer over a
network connection instead of via USB connection.
• If
you switch to printing in an AppleTalk network, see "Configuring the Destination for AppleTalk Networks ."
→P.794
• If
you switch to printing in a TCP/IP network, or if the printer's IP address is changed, see "Configuring the Destina-
tion for TCP/IP Network ."
→P.797
• If you switch to printing in a Bonjour network, see "Configuring the Destination for Bonjour Network ." →P.800
Configuring the Printer's AppleTalk Network Settings
Follow the steps below to configure the AppleTalk network settings.
1. Start
the web browser and enter the following URL in the Location (or Address ) box to display the RemoteUI
page.
http://printer IP address or name/
Example: http://xxx.xxx.xxx.xxx/
2. Select Administrator Mode and click Logon.
3. If a password has been set on the printer, enter the password.
4. Click Network in the Device Manager menu at left to display the Network page.
5. Click Edit in the upper-right corner of the AppleTalk group to display the Edit AppleTalk Protocol Settings page.
6. Refer to the AppleTalk Settings Items table to complete the settings.
AppleTalk Settings Items
Item Details Default Setting
Phase
Type
Specify whether to use AppleTalk.
If you will use AppleTalk, choose Phase 2.
If you will not use AppleTalk, choose Disabled.
Disabled
Name
(*1)
Specify the object name used by AppleTalk (in up to 31 single-byte or 15 double-byte
characters).
However, do not use the following single-byte characters: @, *, :, and =.
Canon
NB-17FB
(xxxxxx)
Zone (*2) Specify the printer zone name, up to 31 single-byte characters. *
Network Setting
> Network Setting (Mac OS X) >
iPF815 Configuring the Printer Driver Destination
10
793

Canon imagePROGRAF iPF815 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Pigment matte black, Yellow
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	5
Package weight	301200 g
Bundled software	Printer Driver Extra Kit for Windows/Mac (Free Layout, Color imageRUNNER Enlargement Copy, Advanced Preview), Print Plug-in for Microsoft Word/Excel/PowerPoint for Windows, Digital Photo Front-Access for Windows, PosterArtist Lite for Windows
Media thickness	0.07 - 0.8 mm
Roll top margin	3 mm
Maximum print size	-
Maximum roll length	18 m
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A0, A1
ISO B-series sizes (B0...B9)	B0, B2
Electromagnetic compatibility	RoHS Directive, WEEE, Executive Order (USA)
Power requirements	AC 100 - 240V, 50/60Hz
Power consumption (off)	1 W
Power consumption (standby)	6 W
Power consumption (typical)	190 W
Certification	UL (USA), C-UL (Canada), S mark (Argentina), CE mark (EN60950, EN55022 classB, EN61000-3-2, EN-61000-3-3, EN55024) (EU), CB certification (Others), FCC Class B (USA), IC Class B (Canada)
Storage media	HDD
Internal storage capacity	160 GB
Sound power level (standby)	35 dB
Sound pressure level (printing)	52 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10/100Base-T/TX Mbit/s
Sustainability certificates	ENERGY STAR
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Compatible operating systems	Windows XP (32/64 bit), Server 2003 (32/64 bit), Server 2008 (32/64 bit), Windows Vista (32/64 bit), Windows 7 (32/64 bit); Macintosh OS X 10.3.9 - 10.6 (32 bit), OS X 10.5 - 10.6 (64 bit)

Weight and Dimensions

Dimensions (WxDxH)	1892 x 975.4 x 1143 mm
