Canon imagePROGRAF iPF815 User Manual

Note
• If
a sheet is loaded when you change the paper source to a roll, "Eject sheet?" is displayed. Press the OK
button and remove the sheet.
• You cannot switch the paper source in the following situations:
• When the Message lamp is flashing
Check the message on the Display Screen and take action as necessary. (See "Error Messag-
es
→P.891 .")
• When the Data lamp is flashing
Select the paper source after printing is finished.
• When a printer menu operation is in progress
Wait until the operation is finished before selecting the paper source.
• When in the process of loading paper
Finish loading the paper before selecting the paper source.
• When in the process of replacing Ink Tank
Finish replacing the Ink Tank before selecting the paper source.
• When the Top Cover is open
Close the Top Cover before selecting the paper source.
Selecting the Paper Type (Roll)
When changing the type of paper after the paper has been advanced, specify the type of paper as follows.
Important
• For
best printing results, the printer fine-tunes the feed amount for each type of paper. Be sure to select the
type of paper to use correctly before printing.
• Because the printer fine-tunes the feed amount for each type of paper, the margins and the size of printed
images may vary depending on the type of paper used. If margins and the size of images are not as you ex-
pected, adjust the paper feed amount and Printhead height.
(See "Adjusting the Feed Amount.")
→P.676
(See "Troubleshooting Paper Abrasion and Blurry Images (Head Height).") →P.675
Note
• After
you load the roll, the printer automatically shows a menu for selection of the paper type on the Display
Screen, unless a barcode has been printed on the roll or you have activated automatic monitoring of the re-
maining roll paper. Select the type of paper, and then press the OK button.
If no barcode has been printed on the roll and you have activated automatic monitoring of the remaining roll
paper, specify the roll length after the paper type. (See "Specifying the Paper Length (Roll).")
→P.633
1. Press the Menu button to display MAIN MENU.
Handling Paper
> Handling rolls >
Selecting the Paper Type (Roll) iPF815
7
632

Canon imagePROGRAF iPF815 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Pigment matte black, Yellow
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	5
Package weight	301200 g
Bundled software	Printer Driver Extra Kit for Windows/Mac (Free Layout, Color imageRUNNER Enlargement Copy, Advanced Preview), Print Plug-in for Microsoft Word/Excel/PowerPoint for Windows, Digital Photo Front-Access for Windows, PosterArtist Lite for Windows
Media thickness	0.07 - 0.8 mm
Roll top margin	3 mm
Maximum print size	-
Maximum roll length	18 m
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A0, A1
ISO B-series sizes (B0...B9)	B0, B2
Electromagnetic compatibility	RoHS Directive, WEEE, Executive Order (USA)
Power requirements	AC 100 - 240V, 50/60Hz
Power consumption (off)	1 W
Power consumption (standby)	6 W
Power consumption (typical)	190 W
Certification	UL (USA), C-UL (Canada), S mark (Argentina), CE mark (EN60950, EN55022 classB, EN61000-3-2, EN-61000-3-3, EN55024) (EU), CB certification (Others), FCC Class B (USA), IC Class B (Canada)
Storage media	HDD
Internal storage capacity	160 GB
Sound power level (standby)	35 dB
Sound pressure level (printing)	52 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10/100Base-T/TX Mbit/s
Sustainability certificates	ENERGY STAR
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Compatible operating systems	Windows XP (32/64 bit), Server 2003 (32/64 bit), Server 2008 (32/64 bit), Windows Vista (32/64 bit), Windows 7 (32/64 bit); Macintosh OS X 10.3.9 - 10.6 (32 bit), OS X 10.5 - 10.6 (64 bit)

Weight and Dimensions

Dimensions (WxDxH)	1892 x 975.4 x 1143 mm
