4. To use the printer in remote printer mode, start the print server.
To
use the NetWare file server as the print server, enter LOAD PSERVER.NLM at the file server and press the
Enter key.
Note
• This procedure is not required when using queue server mode.
Use PCONSOLE to set up the print server if bindery queue server mode or remote printer mode is used.
1. Log into NetWare as Supervisor and start PCONSOLE.
2. Switch to bindery mode.
3. If the print server has not been created, create it.
1. In Available Options, select Quick Setup and press the Enter key.
2. Enter the name of the new print server, the new printer, and the queue.
Note
• The
print server name will be required when configuring the printer's protocol settings. Write down
the print server name for future reference.
4. Specify the printer type.
1. To
use the printer in queue server mode, choose Other/Unknown in Type. To use remote printer mode, set
Printer Type to Parallel and Position to Manual Load.
2. Press the Esc key.
3. After the confirmation message is displayed, choose Yes and press the Enter key.
5. Set a password.
1. In Available Options, select Print Servers and press the Enter key.
2. Select the print server created in step 2 and press the Enter key.
3. Select Password, and press the Enter key to display the password input dialog box.
4. Enter the password and press the Enter key.
6. Press the Esc key several times to display the dialog box for confirming that PCONSOLE is finished.
7. Click Yes to exit PCONSOLE.
Specifying NetWare Protocols
Follow the steps below to configure NetWare protocol settings other than the frame type by using RemoteUI.
Note
• For details on RemoteUI, see "Using RemoteUI."
→P.776
Network Setting
> Network Setting (Windows) >
iPF815 Specifying NetWare Protocols
10
789

Canon imagePROGRAF iPF815 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Pigment matte black, Yellow
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	5
Package weight	301200 g
Bundled software	Printer Driver Extra Kit for Windows/Mac (Free Layout, Color imageRUNNER Enlargement Copy, Advanced Preview), Print Plug-in for Microsoft Word/Excel/PowerPoint for Windows, Digital Photo Front-Access for Windows, PosterArtist Lite for Windows
Media thickness	0.07 - 0.8 mm
Roll top margin	3 mm
Maximum print size	-
Maximum roll length	18 m
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A0, A1
ISO B-series sizes (B0...B9)	B0, B2
Electromagnetic compatibility	RoHS Directive, WEEE, Executive Order (USA)
Power requirements	AC 100 - 240V, 50/60Hz
Power consumption (off)	1 W
Power consumption (standby)	6 W
Power consumption (typical)	190 W
Certification	UL (USA), C-UL (Canada), S mark (Argentina), CE mark (EN60950, EN55022 classB, EN61000-3-2, EN-61000-3-3, EN55024) (EU), CB certification (Others), FCC Class B (USA), IC Class B (Canada)
Storage media	HDD
Internal storage capacity	160 GB
Sound power level (standby)	35 dB
Sound pressure level (printing)	52 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10/100Base-T/TX Mbit/s
Sustainability certificates	ENERGY STAR
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Compatible operating systems	Windows XP (32/64 bit), Server 2003 (32/64 bit), Server 2008 (32/64 bit), Windows Vista (32/64 bit), Windows 7 (32/64 bit); Macintosh OS X 10.3.9 - 10.6 (32 bit), OS X 10.5 - 10.6 (64 bit)

Weight and Dimensions

Dimensions (WxDxH)	1892 x 975.4 x 1143 mm
