Canon imagePROGRAF iPF815 User Manual

1. Start
the web browser and enter the following URL in the Location (or Address ) box to display the RemoteUI
page.
http://printer IP address or name/
Example: http://xxx.xxx.xxx.xxx/
2. Select Administrator Mode and click Logon.
3. If a password has been set on the printer, enter the password.
4. Click Network in the Device Manager menu at left to display the Network page.
5. Click Edit in the upper-right corner of the NetWare group to display the Edit NetWare Protocol Settings page.
6. Make sure the Frame Type indicates the frame type used on the NetWare network.
7. To use burst mode, choose On for NCP Burst Mode.
Note
• Burst mode supports fast data transfer when printing in queue server mode. Normally, choose On.
8. In Print Application, click the print service to be used.
Note
• Only
one print service selected here will be enabled. Multiple print services are not available at the
same time.
9. For packet signature, click If Requested by Server in Packet Signature.
10. Complete the following settings based on the selected service.
• If you have selected Bindery PServer: Queue Server Mode (Using a Bindery Print Server)
1. In File Server Name, enter the file server name.
2. In Print
Server Name, enter the name of the print server created in "Specifying NetWare Print Serv-
ices
→P.787 ."
3. In Print
Server Password, enter the password of the print server created in "Specifying NetWare Print
Services
→P.787 ."
4. In Polling Interval, specify the interval at which the printer checks the NetWare print queue.
• If you have selected RPrinter: Remote Printer Mode (Using a Bindery Print Server)
1. In Print
Server Name, enter the advertising name of the print server created in "Specifying NetWare
Print Services
→P.787 ."
2. In Printer Number, enter the same printer number specified in "Specifying NetWare Print Serv-
ices →P.787 ."
• If you have selected NDS PServer: Queue Server Mode (Using an NDS Print Server)
1. In Tree Name and Context Name, enter the tree and context name of the print server.
Network Setting
> Network Setting (Windows) >
Specifying NetWare Protocols iPF815
10
790

Canon imagePROGRAF iPF815 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Pigment matte black, Yellow
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	5
Package weight	301200 g
Bundled software	Printer Driver Extra Kit for Windows/Mac (Free Layout, Color imageRUNNER Enlargement Copy, Advanced Preview), Print Plug-in for Microsoft Word/Excel/PowerPoint for Windows, Digital Photo Front-Access for Windows, PosterArtist Lite for Windows
Media thickness	0.07 - 0.8 mm
Roll top margin	3 mm
Maximum print size	-
Maximum roll length	18 m
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A0, A1
ISO B-series sizes (B0...B9)	B0, B2
Electromagnetic compatibility	RoHS Directive, WEEE, Executive Order (USA)
Power requirements	AC 100 - 240V, 50/60Hz
Power consumption (off)	1 W
Power consumption (standby)	6 W
Power consumption (typical)	190 W
Certification	UL (USA), C-UL (Canada), S mark (Argentina), CE mark (EN60950, EN55022 classB, EN61000-3-2, EN-61000-3-3, EN55024) (EU), CB certification (Others), FCC Class B (USA), IC Class B (Canada)
Storage media	HDD
Internal storage capacity	160 GB
Sound power level (standby)	35 dB
Sound pressure level (printing)	52 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10/100Base-T/TX Mbit/s
Sustainability certificates	ENERGY STAR
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Compatible operating systems	Windows XP (32/64 bit), Server 2003 (32/64 bit), Server 2008 (32/64 bit), Windows Vista (32/64 bit), Windows 7 (32/64 bit); Macintosh OS X 10.3.9 - 10.6 (32 bit), OS X 10.5 - 10.6 (64 bit)

Weight and Dimensions

Dimensions (WxDxH)	1892 x 975.4 x 1143 mm
