Canon imagePROGRAF iPF815 User Manual

Printing Wizard dialog box
Important
• If
you want to change the display to another file or application while the Printing Wizard is open, close the
Printing Wizard dialog box. Otherwise, you may not be able to change displays or operate the toolbar/rib-
bon.
• The Printing Wizard will not start if you click the Print button on the toolbar/ribbon while editing a cell.
• When more than one worksheet is selected, the Printing Wizard cannot be run. Select only one worksheet
and click Print again.
• When an object is selected, the Printing Wizard is not started if you click the Print button on the toolbar/
ribbon.
• If the paper size in Excel is blank, the Printing Wizard cannot be run. From the File menu in Excel, select
Page Setup and check Paper size.
Note
• If
you click the Print button with a graph selected, a message dialog box will appear asking if you want to
continue printing. If you click No, you will return to the application.
• If you click the Print button with a page break set, a message dialog box will appear asking if you want to
continue printing. If you click No, you will return to the application. If you do not use the set page break,
check the page break preview and change the setting.
• If you click the Print button with a page range set, a message dialog box will appear asking if you want to
continue printing. If you click No, you will return to the application. If you do not use the set page range,
check the page break preview and change the setting.
• If you click the Print button with a worksheet or cell protected, a message dialog box will appear asking if
you want to continue printing. If you click No, you will return to the application. If you want to change the
setting, remove the protection from the worksheet or cell.
Windows Software
> Print Plug-In for Office >
To start from Microsoft Excel iPF815
4
344

Canon imagePROGRAF iPF815 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Pigment matte black, Yellow
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	5
Package weight	301200 g
Bundled software	Printer Driver Extra Kit for Windows/Mac (Free Layout, Color imageRUNNER Enlargement Copy, Advanced Preview), Print Plug-in for Microsoft Word/Excel/PowerPoint for Windows, Digital Photo Front-Access for Windows, PosterArtist Lite for Windows
Media thickness	0.07 - 0.8 mm
Roll top margin	3 mm
Maximum print size	-
Maximum roll length	18 m
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A0, A1
ISO B-series sizes (B0...B9)	B0, B2
Electromagnetic compatibility	RoHS Directive, WEEE, Executive Order (USA)
Power requirements	AC 100 - 240V, 50/60Hz
Power consumption (off)	1 W
Power consumption (standby)	6 W
Power consumption (typical)	190 W
Certification	UL (USA), C-UL (Canada), S mark (Argentina), CE mark (EN60950, EN55022 classB, EN61000-3-2, EN-61000-3-3, EN55024) (EU), CB certification (Others), FCC Class B (USA), IC Class B (Canada)
Storage media	HDD
Internal storage capacity	160 GB
Sound power level (standby)	35 dB
Sound pressure level (printing)	52 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10/100Base-T/TX Mbit/s
Sustainability certificates	ENERGY STAR
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Compatible operating systems	Windows XP (32/64 bit), Server 2003 (32/64 bit), Server 2008 (32/64 bit), Windows Vista (32/64 bit), Windows 7 (32/64 bit); Macintosh OS X 10.3.9 - 10.6 (32 bit), OS X 10.5 - 10.6 (64 bit)

Weight and Dimensions

Dimensions (WxDxH)	1892 x 975.4 x 1143 mm
