• Paper type: Plain Paper
• Roll paper width: A2/A3 roll (420.0 mm [16.5 in])
1. Choose Print in the application menu.
2. Select
the printer in the dialog box, and then display the printer driver dialog box.(See "Accessing the Printer Driv-
er Dialog Box from Applications (Windows)
→P.211 ")
3. Make sure the Main sheet is displayed.
4. In the A Media Type list, select the type of paper that is loaded. In this case, click Plain Paper.
5. After
confirming that D Easy Settings is selected, click CAD (Color Line Drawing) or CAD (Monochrome Line
Drawing ) in the E Print Target list.
Note
• You can check the settings values selected in the E Print Target list by clicking G View Settings.
Working With Various Print Jobs
>
Printing CAD Drawings
>
iPF815 Printing Line Drawings and Text (Windows)
2
21
