Canon imagePROGRAF iPF815 User Manual

Note
• The
settings in the Paper Detailed Settings dialog box are temporary; after the print job finishes the settings
of the printer operation panel are restored.
Drying Time
Between Pages
This sets the wait time for the ink to dry between each completely printed sheet and the output of the sheet.
Setting Details
Printer Default The settings of the printer operating panel are applied.
None The paper is ejected immediately after printing.
30sec. / 1min. / 3min. / 5min. /
10min. / 30min. / 60min.
The sheet is ejected when the specified time after printing has elapsed.
Between Scans
This sets the wait time between line scans during printing.
Setting Details
Printer Default The settings of the printer operating panel are applied.
None The printing continues to the next line immediately after the last line.
1sec. / 3sec. / 5sec. / 7sec. / 9sec. The printing continues to the next line after the set time.
*For the media type that has problems, such as ink smears on the page or colors
that seem uneven during borderless printing etc., increase the value for this setting.
Roll Paper Margin for Safety
Near End Margin
This sets the length of the near end margin of the roll paper.
Setting Details
Printer Default The settings of the printer operating panel are applied.
3mm Print at a standard size.
*Select for Media Type that has no problem when printing with a standard size
margin.
20mm This setting sets the margin about 17 mm (in the feed direction) longer than the
standard margin for the media size.
*This is for Media Type that has a strong tendency to curl, causing the printhead to
scratch the surface.
Important
• If
you make the margin (white space) too small, this could disturb the print image or cause the printhead to
scour the surface of some types of media. If the printhead scours the surface of the media, adjust the height of
the printhead.
Cut Speed
This selects the auto cut speed.
Windows Software
> HDI Driver >
iPF815 Paper Detailed Settings
4
381

Canon imagePROGRAF iPF815 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Pigment matte black, Yellow
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	5
Package weight	301200 g
Bundled software	Printer Driver Extra Kit for Windows/Mac (Free Layout, Color imageRUNNER Enlargement Copy, Advanced Preview), Print Plug-in for Microsoft Word/Excel/PowerPoint for Windows, Digital Photo Front-Access for Windows, PosterArtist Lite for Windows
Media thickness	0.07 - 0.8 mm
Roll top margin	3 mm
Maximum print size	-
Maximum roll length	18 m
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A0, A1
ISO B-series sizes (B0...B9)	B0, B2
Electromagnetic compatibility	RoHS Directive, WEEE, Executive Order (USA)
Power requirements	AC 100 - 240V, 50/60Hz
Power consumption (off)	1 W
Power consumption (standby)	6 W
Power consumption (typical)	190 W
Certification	UL (USA), C-UL (Canada), S mark (Argentina), CE mark (EN60950, EN55022 classB, EN61000-3-2, EN-61000-3-3, EN55024) (EU), CB certification (Others), FCC Class B (USA), IC Class B (Canada)
Storage media	HDD
Internal storage capacity	160 GB
Sound power level (standby)	35 dB
Sound pressure level (printing)	52 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10/100Base-T/TX Mbit/s
Sustainability certificates	ENERGY STAR
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Compatible operating systems	Windows XP (32/64 bit), Server 2003 (32/64 bit), Server 2008 (32/64 bit), Windows Vista (32/64 bit), Windows 7 (32/64 bit); Macintosh OS X 10.3.9 - 10.6 (32 bit), OS X 10.5 - 10.6 (64 bit)

Weight and Dimensions

Dimensions (WxDxH)	1892 x 975.4 x 1143 mm
