Canon imagePROGRAF iPF815 User Manual

f.
Stationary Output Stacker
A cloth tray that catches ejected documents. (See "Stationary Output Stacker.") →P.658
g.
Paper Feed Slot
When loading a roll, insert the edge of the roll paper here.
h.
Holder Stopper
Secure rolls on the Roll Holder with this part.
i.
Ink Tank Cover
Open this cover to replace an Ink Tank. (See "Ink Tank Cover (Inside).") →P.690
j.
Control Panel
Use this panel to operate the printer and check the printer status. (See "Control Panel.") →P.692
k.
Release Lever
Releases the Paper Retainer. Lift this lever toward the front of the printer when loading paper.
l.
Maintenance Cartridge
Ink used for maintenance purposes such as head cleaning is absorbed. (Replace the cartridge when it is full.)
m.
Carrying Handles
When carrying the printer, have six people hold it by these handles under both sides.
n.
Maintenance Cartridge Cover
Open this cover to replace the Maintenance Cartridge.
o.
Stand
A stand that holds the printer. Equipped with casters to facilitate moving it.
p.
Stand L
The left leg of the Stand.
q.
Stand R
The right leg of the Stand.
r.
Top Stand Stay
Supports Stand L and Stand R. Attach the optional Media Take-up Unit to this part.
s.
Leg Covers
Covers for Stand L and Stand R.
t.
Stopper
Locks the Stand casters.
Always
release the Stopper before moving the printer. Moving the printer while the Stopper is locked may scratch the
casters or the floor.
Printer Parts
> Printer parts >
Front iPF815
9
686

Canon imagePROGRAF iPF815 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Pigment matte black, Yellow
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	5
Package weight	301200 g
Bundled software	Printer Driver Extra Kit for Windows/Mac (Free Layout, Color imageRUNNER Enlargement Copy, Advanced Preview), Print Plug-in for Microsoft Word/Excel/PowerPoint for Windows, Digital Photo Front-Access for Windows, PosterArtist Lite for Windows
Media thickness	0.07 - 0.8 mm
Roll top margin	3 mm
Maximum print size	-
Maximum roll length	18 m
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A0, A1
ISO B-series sizes (B0...B9)	B0, B2
Electromagnetic compatibility	RoHS Directive, WEEE, Executive Order (USA)
Power requirements	AC 100 - 240V, 50/60Hz
Power consumption (off)	1 W
Power consumption (standby)	6 W
Power consumption (typical)	190 W
Certification	UL (USA), C-UL (Canada), S mark (Argentina), CE mark (EN60950, EN55022 classB, EN61000-3-2, EN-61000-3-3, EN55024) (EU), CB certification (Others), FCC Class B (USA), IC Class B (Canada)
Storage media	HDD
Internal storage capacity	160 GB
Sound power level (standby)	35 dB
Sound pressure level (printing)	52 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10/100Base-T/TX Mbit/s
Sustainability certificates	ENERGY STAR
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Compatible operating systems	Windows XP (32/64 bit), Server 2003 (32/64 bit), Server 2008 (32/64 bit), Windows Vista (32/64 bit), Windows 7 (32/64 bit); Macintosh OS X 10.3.9 - 10.6 (32 bit), OS X 10.5 - 10.6 (64 bit)

Weight and Dimensions

Dimensions (WxDxH)	1892 x 975.4 x 1143 mm
