c.
Data lamp (Green)
•
Flashing
During printing, the Data lamp flashes when the printer is receiving or processing print jobs. Otherwise, this lamp
flashes when the print job is paused or the printer is updating the firmware.
•
Off
There are no active print jobs when the Data lamp is off.
d.
Message lamp (Orange)
•
On
A warning message is displayed.
•
Flashing
An error message is displayed.
•
Off
The printer is off or is operating normally.
e.
Paper Source Section
After you press the Feeder Selection button, the lamp for your chosen paper source is lit.
1.
Roll Media lamp (Green)
•
On
Indicates that a roll is selected as the paper source.
•
Off
Indicates that a sheet is selected as the paper source.
2.
Cut Sheet lamp (Green)
•
On
Indicates that a sheet is selected as the paper source.
•
Off
Indicates that a roll is selected as the paper source.
f.
Feeder Selection Button
Switches the paper source. Each time you press this button, the paper source switches between the roll and the sheet,
and the corresponding lamp on the Paper Source Section is lit.
g.
Display Screen
Shows the printer menu, as well as the printer status and messages.
h.
Color Label
This label indicates the Ink Tank color. The label corresponds to the ink level on the Display Screen.
i.
HDD lamp (Green)
•
On
Indicates the printer is accessing the hard disk.
•
Off
Indicates the printer is not accessing the hard disk.
j.
◀ Button
Menu mode: Press this button to display the menu one level higher.
Printer Parts
> Control Panel >
iPF815 Control Panel
9
693

Canon imagePROGRAF iPF815 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Pigment matte black, Yellow
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	5
Package weight	301200 g
Bundled software	Printer Driver Extra Kit for Windows/Mac (Free Layout, Color imageRUNNER Enlargement Copy, Advanced Preview), Print Plug-in for Microsoft Word/Excel/PowerPoint for Windows, Digital Photo Front-Access for Windows, PosterArtist Lite for Windows
Media thickness	0.07 - 0.8 mm
Roll top margin	3 mm
Maximum print size	-
Maximum roll length	18 m
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A0, A1
ISO B-series sizes (B0...B9)	B0, B2
Electromagnetic compatibility	RoHS Directive, WEEE, Executive Order (USA)
Power requirements	AC 100 - 240V, 50/60Hz
Power consumption (off)	1 W
Power consumption (standby)	6 W
Power consumption (typical)	190 W
Certification	UL (USA), C-UL (Canada), S mark (Argentina), CE mark (EN60950, EN55022 classB, EN61000-3-2, EN-61000-3-3, EN55024) (EU), CB certification (Others), FCC Class B (USA), IC Class B (Canada)
Storage media	HDD
Internal storage capacity	160 GB
Sound power level (standby)	35 dB
Sound pressure level (printing)	52 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10/100Base-T/TX Mbit/s
Sustainability certificates	ENERGY STAR
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Compatible operating systems	Windows XP (32/64 bit), Server 2003 (32/64 bit), Server 2008 (32/64 bit), Windows Vista (32/64 bit), Windows 7 (32/64 bit); Macintosh OS X 10.3.9 - 10.6 (32 bit), OS X 10.5 - 10.6 (64 bit)

Weight and Dimensions

Dimensions (WxDxH)	1892 x 975.4 x 1143 mm
