If action can be taken If no action can be taken
Take the appropriate action. (See "Error Messag-
es →P.891 .")
Turn off the printer and wait at least three seconds before
restoring the power.
If the message is still displayed after this, write down the
error code and message, turn off the printer, and contact
the Canon dealer for assistance.
Menu mode, and state of the Control Panel
Main menu Menu items and settings Main menu (during printing)
• Display Screen
Pressing
the Menu button when
printing is not in progress displays
the main menu.
The title of the selected menu is
displayed on the first line, and
menus immediately under the cur-
rent menu are displayed on the
second and subsequent lines.
Lower level menus are available if
▶ is displayed at right. (See
"Main Menu Operations.")
→P.705
• Display Screen
The
title of the selected menu is
displayed on the first line, and
menu items or settings are dis-
played on the second and subse-
quent lines. (See "Main Menu
Operations.")
→P.705
The
menu of options available
during printing (top figure) can
be displayed by pressing the ▶
button when the main menu is
displayed (left figure).
• Display Screen
Menus
available during printing are
displayed if you press the Menu
button during printing.
If you select a menu, the title of the
selected menu is displayed on the
first line, and menus immediately
under the current menu are dis-
played on the second and subse-
quent lines. Lower level menus are
available if ▶ is displayed at right.
(See "Main Menu Operations.")
→P.705
Submenu mode, and state of the Control Panel
Remaining Maintenance
Cartridge capacity and ink
levels
Information on the loaded
paper
Printer information
HP-GL/2 setting informa-
tion
Press the Information button to display this information, one after another: the Maintenance Cartridge capacity and
remaining ink levels, paper information, printer information, and GL2 settings information. (See "Submenu Display.")
→P.735
Printer Parts
> Control Panel >
iPF815 Printer Modes
9
701

Canon imagePROGRAF iPF815 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Pigment matte black, Yellow
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	5
Package weight	301200 g
Bundled software	Printer Driver Extra Kit for Windows/Mac (Free Layout, Color imageRUNNER Enlargement Copy, Advanced Preview), Print Plug-in for Microsoft Word/Excel/PowerPoint for Windows, Digital Photo Front-Access for Windows, PosterArtist Lite for Windows
Media thickness	0.07 - 0.8 mm
Roll top margin	3 mm
Maximum print size	-
Maximum roll length	18 m
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A0, A1
ISO B-series sizes (B0...B9)	B0, B2
Electromagnetic compatibility	RoHS Directive, WEEE, Executive Order (USA)
Power requirements	AC 100 - 240V, 50/60Hz
Power consumption (off)	1 W
Power consumption (standby)	6 W
Power consumption (typical)	190 W
Certification	UL (USA), C-UL (Canada), S mark (Argentina), CE mark (EN60950, EN55022 classB, EN61000-3-2, EN-61000-3-3, EN55024) (EU), CB certification (Others), FCC Class B (USA), IC Class B (Canada)
Storage media	HDD
Internal storage capacity	160 GB
Sound power level (standby)	35 dB
Sound pressure level (printing)	52 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10/100Base-T/TX Mbit/s
Sustainability certificates	ENERGY STAR
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Compatible operating systems	Windows XP (32/64 bit), Server 2003 (32/64 bit), Server 2008 (32/64 bit), Windows Vista (32/64 bit), Windows 7 (32/64 bit); Macintosh OS X 10.3.9 - 10.6 (32 bit), OS X 10.5 - 10.6 (64 bit)

Weight and Dimensions

Dimensions (WxDxH)	1892 x 975.4 x 1143 mm
