Note
• When rewinding heavyweight paper, use strong adhesive tape to fasten it.
14. Press
the Online button to bring the printer offline, and then press ▼ on the Control Panel to loosen the tension of
the roll.
15. On
the Right Media Take-up Unit, pull the Rewind Mode Switch forward to turn it on. Press the ▼ button on the
Media Take-up Unit to rewind the roll so that it is nearly taut.
Important
• Rewind
the paper so that the paper core makes at least two revolutions. If the paper is not rewound
two full revolutions, repeat steps 14 and 15.
• Do not manually force the Rewind Spool or paper core to rotate them. This may damage them. To
rewind or unwind rolls, press ▲ or ▼ on the Media Take-up Unit.
Printer Parts
>
Optional accessories
>
Using the Media Take-up Unit iPF815
