Important
• The
inside surfaces of Safety Cap 1 (a) and Safety Cap 2 (b) are coated with ink to protect the noz-
zles. Be careful not to touch these surfaces when removing the caps.
• Never touch the ink supply section (d). This may cause printing problems.
• The Printhead contains ink to protect the nozzles. We recommend removing Safety Cap 2 (b) as you
hold it over the Printhead package or safely out of the way to avoid spilling ink and staining your
clothes or the surrounding area. If ink accidentally spills, wipe off the ink with a dry cloth.
• Do not reattach the Safety Cap or protective material. Dispose of these materials in accordance with
local regulations.
15. With
the nozzles facing down and the metal contacts toward the back, insert the Printhead into the Carriage. Careful-
ly push the printhead firmly into the Carriage, ensuring that the nozzles and metal contacts do not touch the carriage.
16. Pull the Printhead Fixer Cover down toward the front to lock the Printhead in place.
17. Push the Printhead Fixer Lever toward the back of the printer until it clicks.
Maintenance
>
Printheads
>
iPF815 Replacing the Printhead
11
825
To Next Page
