Canon imagePROGRAF iPF815 User Manual

After you execute Repl. maint cart and replace the Maintenance Cartridge, a message will appear on the Display Screen
requesting you to replace the Shaft Cleaner. Select Yes and press the OK button. Next, go to step 4.
1. Press the Menu button to display MAIN MENU.
2. Press ▲ or ▼ to select Maintenance, and then press the ▶ button.
3. Press ▲ or ▼ to select Repl. S. Cleaner, and then press the ▶ button.
4. Press ▲ or ▼ to select Yes, and then press the OK button.
After the Carriage is moved, the Display Screen indicates "Open Upper Cover".
Note
• If
you do not respond within two minutes, shaft cleaner replacement is canceled and the printer goes
online automatically. In this case, repeat the procedure.
5. Open the Top Cover.
Note
• Do not open the Printhead Fixer Lever toward the front.
Accidentally
opening the Printhead Fixer Lever toward the front will draw out ink, which consumes
ink.
Maintenance
> Maintenance Cartridge >
iPF815 Replacing the Maintenance Cartridge
11
833

Canon imagePROGRAF iPF815 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Pigment matte black, Yellow
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	5
Package weight	301200 g
Bundled software	Printer Driver Extra Kit for Windows/Mac (Free Layout, Color imageRUNNER Enlargement Copy, Advanced Preview), Print Plug-in for Microsoft Word/Excel/PowerPoint for Windows, Digital Photo Front-Access for Windows, PosterArtist Lite for Windows
Media thickness	0.07 - 0.8 mm
Roll top margin	3 mm
Maximum print size	-
Maximum roll length	18 m
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A0, A1
ISO B-series sizes (B0...B9)	B0, B2
Electromagnetic compatibility	RoHS Directive, WEEE, Executive Order (USA)
Power requirements	AC 100 - 240V, 50/60Hz
Power consumption (off)	1 W
Power consumption (standby)	6 W
Power consumption (typical)	190 W
Certification	UL (USA), C-UL (Canada), S mark (Argentina), CE mark (EN60950, EN55022 classB, EN61000-3-2, EN-61000-3-3, EN55024) (EU), CB certification (Others), FCC Class B (USA), IC Class B (Canada)
Storage media	HDD
Internal storage capacity	160 GB
Sound power level (standby)	35 dB
Sound pressure level (printing)	52 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10/100Base-T/TX Mbit/s
Sustainability certificates	ENERGY STAR
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Compatible operating systems	Windows XP (32/64 bit), Server 2003 (32/64 bit), Server 2008 (32/64 bit), Windows Vista (32/64 bit), Windows 7 (32/64 bit); Macintosh OS X 10.3.9 - 10.6 (32 bit), OS X 10.5 - 10.6 (64 bit)

Weight and Dimensions

Dimensions (WxDxH)	1892 x 975.4 x 1143 mm
