CHAPTER 6 FIXING SYSTEM
COPYRIGHT © 1999 CANON INC. CANON PC800s/900s REV.0 AUG. 1999 PRINTED IN JAPAN (IMPRIME AU JAPON) 6-2
Figure 6-101
Figure 6-102
Cleaning roller
Fixing lower roller
Fixing thermistor (TH1)
Thermal fuse 2 (FU2)
Fixing film
Fixing heater (H1)
M1
Fixing thermistor signal (TH1)
DC controller PCB
Composite power supply PCB
Main motor
Fixing lower roller
Cleaning roller
Fixing film
Fixing heater (H1)
Thermal fuse 2 (FU2)
Fixing thermistor (TH1)
