B. External Covers
Remove the covers as follows when
cleaning, checking, or repairing the inside of
the machine:
1) Remove the ADF from the copier.
(See “A. Removing the ADF.”)
2) Remove the feeding roller [1] from the
bushing [2].
[1] Upper cover [2] Lower cover
Figure 8-206
Figure 8-207
[1]
[2]
[1]
[2]
[1]
[2]
