CHAPTER 11 TROUBLESHOOTING
COPYRIGHT © 1999 CANON INC. CANON PC800s/900s REV.0 AUG. 1999 PRINTED IN JAPAN (IMPRIME AU JAPON) 11-80
B. Switches
Figure 11-602
Description
Door switch
Power switch
Density correction switch
Symbol Name
Switch
Switch
Notation
DS1
SW309
SW101
Remarks
DS1
SW309
SW101
